MAN TGE Van Racking Kits

Filter by Van Model (Year) and Van Size to find kit options to suit your specific van.

Which van have you got?

Pick your size to see only the kits that fit it.

Make
Generation
Van Size

Can't see your van?

MAN TGE racking: sizes and the kit that fits

Load length, offside and nearside fit, and roof height for the MAN TGE, with the StowPro kit built for each body.

MAN TGE (2017 on) load dimensions and the kit that fits

Body Also searched as Load length Load height Offside run Nearside run
MWB Standard. L2H2, L2H3. Some sellers call this L3 3,450 mm 1,726 to 2,189 mm 2,750 mm 1,250 mm
LWB Long. L3H3. Some sellers call this L4 4,300 mm 1,726 to 2,189 mm 3,750 mm 2,030 mm
Maxi Extra long. L4H3, L4H4. Some sellers call this L5 4,855 mm 1,726 to 2,189 mm 3,750 mm 2,030 mm

Load width 1,832 mm · between wheel arches 1,380 mm · roof heights H2 1,726 / H3 1,961 / H4 2,189 mm · side door aperture 1,311 mm (nearside).

Shop MAN TGE racking →

Offside or nearside?

Bird's-eye view of a right-hand-drive panel van: the offside (driver's side) takes one clear racking run from bulkhead to rear doors; the nearside (passenger side) racking is split by the sliding door.
Offside: one clear run Nearside: split by the sliding door

Bird's-eye view of a typical UK right-hand-drive van, with the standard single nearside sliding door.

Offside · driver's side

The longer run

The offside normally has no door breaking it up, so it takes the longest continuous racking run. That makes it the best wall for long items and full-height units.

Choose: Offside Only

Nearside · passenger side

Around the side door

The sliding load door splits this wall, so the nearside kit is modular fore and aft of the aperture, keeping loading access clear.

Choose: Nearside Only

Racking both walls? The Full Kit covers offside and nearside together.

The TGE is the Volkswagen Crafter with a MAN badge, identical load dimensions, so the codes and the kits are the same for both. Some racking sellers number these vans a size higher, so if you have seen yours written both ways, go by the load length in the table rather than the code. Floor dimensions from manufacturer data. Offside and nearside run widths are taken from StowPro product listings.

MAN TGE racking: common questions

What length racking fits in a MAN TGE Standard on the offside?

On a MAN TGE Standard (L2) the offside gives the longest single racking run, along a load length of 3,450 mm.

The StowPro Offside kit runs 2,750 mm of shelving before the rear doors. The driver's-side wall is the best place for your longest run. For this side only choose the Offside Only kit; for both walls choose the Full Kit.

How long is the load area in a MAN TGE?

The MAN TGE load length is 3,450 mm on the Standard (L2), 4,300 mm on the Long (L3) and 4,855 mm on the Extra long (L4), measured along the floor.

Load width is 1,832 mm, narrowing to 1,380 mm between the wheel arches. StowPro build a kit for each of these bodies, so you match the rack to your exact van.

Do I need the nearside or offside racking kit for my MAN TGE?

Choose the Offside (driver's side) kit for the longest uninterrupted run, the Nearside (passenger side) kit to rack around the sliding door, or the Full Kit to fit out both walls.

On the MAN TGE the standard sliding load door is on the nearside, so that side is split into shorter modules while the offside takes the longer run. Most trades kitting out a whole van take the Full Kit.

Is MAN TGE racking the same as VW Crafter racking?

Yes. The MAN TGE and VW Crafter are the same van with different badges and identical load dimensions, so StowPro racking built for one fits the others.

Match the body length and roof height and the kit is interchangeable across the badge-engineered twins.

How much headroom is there for tall racking in a MAN TGE?

The MAN TGE offers H2 1,726 / H3 1,961 / H4 2,189 mm of internal load height depending on the roof, so taller units and vertical storage fit on the higher-roof bodies.

Check your roof code, H2, H3 or H4 on this van, before choosing full-height shelving. The standard roof takes less than the high or super-high.

Does front- or rear-wheel drive change the racking fit on a MAN TGE?

It can. Rear-wheel-drive MAN TGE vans sit higher, losing roughly 70 to 100 mm of internal height, and twin-rear-wheel models narrow the gap between the wheel arches.

The load length is unchanged, so the offside/nearside kit choice is the same; just allow for the lower roof height and check the arch width if you're on twin wheels.

Will fitting racking reduce my MAN TGE payload?

Racking uses some of the MAN TGE's payload, but StowPro units are built from lightweight load-rated steel to keep that to a minimum.

Fit only the side(s) you need (Offside, Nearside or Full Kit) and keep heavy stock low and central to protect your remaining payload and handling.

What's the longest item I can carry down the side of a MAN TGE?

Long items travel at floor level in a MAN TGE: the 4,855 mm load length on the largest body is measured along the floor, and StowPro racking sits against the wall so the load floor in front of it stays clear.

Don't plan on carrying a full-length item on top of the racking. Higher up the bulkhead and cab seats intrude, so the usable length above the floor is shorter than the floor figure. The offside kit itself runs 3,750 mm along the wall; tell us your body and roof and we'll confirm what fits.

Van Racking for the MAN TGE

The TGE is a Crafter wearing a truck badge, and it's quietly become a favourite with fleets that want big-van space with commercial backup. We rack it from L3 to L5, medium and high roof.

One of our favourite customer fits was a MAN TGE service van, and it shows the range off well: open shelving on one side for the bulk, drawers on the other for the small parts, everything strapped, sorted and reachable. Shelving kits give you 40kg-rated steel shelves and top trays. Workshop kits add the drawer bank and a birch worktop. The Workstation kit turns the back of the van into the workshop itself.

Racking a van this size is about time as much as tidiness: a fitter who isn't hunting for tools gets through more calls in a day, and that's what pays for the kit.

Everything is manufactured and assembled in Devon from heavy duty, hard-wearing steel with sturdy fabricated end frames, and covered by a 3 year guarantee.

Kits arrive palletised, already built. Position the units, fix them to the floor and sides with the brackets and fixings supplied, and follow the installation guide, with our team a call away.

Because the TGE and Crafter share a bodyshell, kits cross over, and most also fit the Sprinter, Transit and Daily. Every kit's fitment list carries the years and sizes. Mats, bins and end frame accessories finish the job.
